Mechanical testing laboratory

Fields of application of the devices in mechanical testing:

Determination of single- point characteristics of molding compounds according to DIN EN ISO 1035-1:

  • Multipurpose specimen DIN EN ISO 3167
  • Tensile test DIN EN ISO 527-1/-2
  • Bending test DIN EN ISO 178 procedures A and B
  • Impact bending test (Charpy) DIN EN ISO 179-1, 23° to -30°
  • Impact bending test (Charpy instrumented) DIN EN ISO 179-2, 23° to -30°
  • Impact tensile test DIN EN ISO 8256 method A



Universal testing machine Zwick/Roell Z100 Allround-Line

Zwick temperature chamber, Source: IfBB
Zwick temperature chamber, Source: IfBB

Technical details:

  • Force transducer: 100 kN class 1
  • Force transducer: 5 kN class 1
  • E-modulus: makroXtens II
  • Width change: videoXtens width to determine the Poisson number μ according to ISO 527-1
  • Sample holder: wedge screw sample holder 100 kN
  • Temperature chamber (-80 °C to +250 °C)

Universal testing machine Zwick/Roell Z020 Allround-Line

Technical Details:

  • Force transducer: 20 kN class 1
  • E-modulus: makroXtens
  • Sample holder: wedge screw sample holder max. 10 kN
  • pneumatic specimen grips, type 8497 30 kN



Table tester Zwick/Roell Z2,5 TN zwicki-Line

Table tester Zwick/Roell Z2,5 TN zwicki-Line, Source: IfBB
Table tester Zwick/Roell Z2,5 TN zwicki-Line, Source: IfBB

Technical details:

  • Force transducers: 2.5 kN Class 1,500 N Class 1, 20 N Class 1
  • Sample holder: Screw sample holding max. 1 kN
  • Specimens: foils, paper/cardboard, fleece

Pendulum impact tester Zwick/Roell HIT25P

Pendulum impact tester Zwick/Roell HIT25P, Source: IfBB
Pendulum impact tester Zwick/Roell HIT25P, Source: IfBB

Technical details:

  • Pendulum: 2-7.5 joule Charpy DIN EN ISO 179-1
  • Pendulum: 5-25 joule instrumented Charpy DIN EN ISO 179-2
  • Pendulum: 2-25 joule impact test DIN EN ISO 8256
  • Specimen: Charpy: Specimen Type 1A
  • Impact tensile test: Type 1
